Lenovo IBM Thinkpad Views |
|
|
 |
|
 |
|
|
Front |
|
1-infrared port, 2-wifi switch,
3-speakers, 4-one hand latch |
|
|
|
|
 |
|
|
 |
|
 |
|
| |
|
|
|
|
|
|
Back |
|
1-battery, 2-charger jack |
|
|
|
|
 |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
Right |
|
1-Hard drive, 2-CDRW/DVD drive, 3-
2xUSB, 4- Lock slot |
|
|
|
|
 |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
Left |
|
1-monitor, 2-Modem, 3-Network, 4-mic
in, 5-headphone, 6-USB, 7-pc card,
8-express |
|
|
|
|
 |
|
|
|
|
|
|
|
|
|
| |
|
|
|
Processor |
-
Available processors
are Intel Mobile
core Duo at 1.8 GHz
T2400
-
Front side bus
667mhz
|
|
Memory |
-
64-bit Double Data
Rate (DDR2)
non-parity SDRAM
memory , 667 MHz , Two 200 pin
SO-DIMM memory
slots,
-
Supports up to two
1GB SDRAM SO DIMMs ,
Supports maximum
memory up to 4GB
|
|
Hard disk drive (HDD)
features |
-
Standard
80GB,HDD, 5400 rpm
-
Supports one
additional HDD which
can be used
concurrently to
offer expanded
storage in the
Ultrabay Slim
-
S.M.A.R.T technology
to issue an alert if
a hardware failure
is pending , ATA Bus
Interface
|
|
Display |
|
|
|
Graphic Controller |
|
|
|
|
Audio |
- Intel
High Definition Audio Full-duplex audio on the system board
- Volume up, down, and mute buttons
- Audio jacks in/out jacks:
- External stereo speakers
- Headphone
- External microphone
- Supports Microsoft DirectSound applications.
|
|
Keyboard |
- Imbedded numeric keypad and integrated UltraNav dual-pointing system, featuring TrackPoint and customized touch pad for the ultimate in pointing flexibility.
- ThinkVantage button, ThinkLight keyboard light, individual volume up, down, and mute buttons.
- The keyboard has a Fn key which is a special key and is located in the lower left corner. The Fn key allows the user to instantly activate the following operational features by pressing the Fn key and a designated function key:
- Standby/Suspend/Hibernation
- Switching between Display device
- Fingerprint reader is integrated into the palm rest of the ThinkPad notebook computer to prevent unauthorized access to your notebook and data.
|
|
Mouse |
- All systems come with the UltraNav dual-pointing system, featuring TrackPoint and customized touch pad for the ultimate in pointing flexibility is a part of the keyboard. The TrackPoint features Press-to-Select, Internet scroll, and magnifying glass for accurate and convenient control.
|
|
|
|
|
Infrared (IR) |
- IR transceiver for wireless file and data transfer and printing., Speeds up to 4Mbps.Compatible with the Infrared Data Association (IrDA) IR data link specification
|
|
Modem |
- Selected models have a modem communication daughter card (CDC) , K56Flex v.92
|
|
Network |
- 1Gb Ethernet installed on systems via the system board.
- ThinkPad 802.11abg Mini PCI Express wireless adapter on selected models.
|
|
|
|
|
Bays |
- One integrated, easy-loading modular Ultrabay Slim
- Type II PC Card slot
- One CDC slot (not a CRU)
|
|
External ports |
- Three USB ports version 2.0
- Additional connector supports the optional Port Replicator, advanced dock, and advanced mini-dock.
- Audio ports
- External stereo speakers or headphone
- Microphone-in
- CRT port for external monitor
- Built-in RJ-11 and RJ-45 connectors for telephony and LAN connections
|
|
PC Card |
- Conforms to the PC Card Standard 95
- Type II slot
- Both the 16-bit Release 2.1 card standard and the 32-bit CardBus card are supported.
|
|
|
|
|
Physical specifications System: |
System:
- Width: 334 mm (13.1 in)
- Depth: 228 mm (9.0 in)
- Height: 26.6 to 30.9 mm (1.05 to 1.22 in)
- Configured system weight:
- With black top cover, four-cell battery, and travel bezel: 1.89 kg (4.17 lb)
- With black top cover, seven-cell battery, and travel bezel: 2.05 kg (4.53 lb)
- With titanium top cover, four-cell battery, and travel bezel: 2.0 kg (4.42 lb)
- With titanium top cover, seven-cell battery, and travel bezel: 2.16 kg (4.77 lb)
|
| Physical specifications Accessories: |
- Battery pack (Li-Ion): 325 g (0.72 LB) AC adapter: 360 g (0.795 LB) DVD drive: 345 g (0.76 LB)
|
|
|
|
|
AC Adapter |
- AC adapter: This ac-to-dc converter supplies the necessary power to the computer. The ac adapter also charges the battery pack when it is installed in the computer.
- Universal AC adapter (90 W):
- Input is 100/240 V ac, 1.7/0.6 A, 50/60 Hz
- Output is 20 V dc, 4.5 A
|
|
Battery |
- The battery pack is an internal power source to the computer when the ac adapter is not available. The battery pack is rechargeable and is charged using the ac adapter with the system.
- You can manage the battery power by using the Battery MaxiMiser and Power Management Features utility.
- A different Li-Ion battery pack fits into the Ultrabay Slim so that two batteries can be installed to increase battery operating time.
- A four or seven cell Li-Ion battery pack is shipped with the system.
- Li-Ion battery pack:
- four cell, 10.8 V, 37.44 Wh
- seven cell, 10.8 V, 65.52 Wh
- Approximate operation and charging hours are:
- Power off/suspend charging(*1):
- Four-cell battery: 3.5 hours
- Seven-cell battery: 4.7 hours
- Charging during operation(*1):
- Four-cell battery: 3.5 to 6.0 hours
- Seven-cell battery: 4.7 hr to 8.0 hours
- Battery operation (Intel Pentium models)(*1):
- Four-cell battery: Up to 3.0 hours
- Seven-cell battery: Up to 5.0 hours
|
|
|
|
|
System |
- Security Chip on selected models
- Fingerprint reader on selected models, offers users a convenient solution, authenticate at system startup and log on to Windows with a swipe of your finger.
- Locking device in the security slot provides physical security.
- The ThinkPad Embedded Security Subsystem provides for authentication and encryption of data communications.
|
|
|
|
|
|
|
|
|
 |
